Android思源字体高度问题研究及字体ymax等处理深度研究 所属栏目:编码知识 23年04月13日 标签:

在这里插入图片描述
原理:

安卓的字体有5个线
在这里插入图片描述

(1)top = 字体中 -head.yMax / head.Units per Em
(2)ascent = 首选 -hhea.Ascent / head.Units per Em,如果没有hhea,则用-OS/2.TypoAscender / head.Units per Em
(3)baseline,基线
(4)descent = 首选 -hhea.Descent / head.Units per Em,如果没有hhea,则用-OS/2.TypoDescender / head.Units per Em
(5)bottom = 字体中 -head.yMax / head.Units per Em

默认的:

head.xMin = FontBBox.xMin
head.yMin = FontBBox.yMin
head.xMax = FontBBox.xMax
head.yMax = FontBBox.yMax
head和FontBBox都是计算得到的。

直接原因:
思源字体在不同平台底下留白的字段有多种,比如 @孫志貴 发现的LineGap,所以思源黑体在V1.002时LineGap改为0。比如 @厉向晨 发现的Adobe的排版时,使用了FontBBox字段。但是安卓中并不使用这个字段,而是head段。

根本原因:
是因为类似于竖排破折号(有两个字高度和三个字高度)导致FontBBox和head字段被撑大了,而Android又依赖于head.yMin和head.yMax来写字导致的。

特殊的字可以见这个:tamcy/CYanHeiHK

解决办法:
1、基于已经发布的字库,用adobe的字库工具修改后重新生成。

2、通过设置textview.setIncludeFontPadding(false)来使用ascent/descent而非top/bottom(即head.yMax/head.yMin)来进行排版。

工具:

查看字体Metrics的方法:

pip install font-lines
font-line report xx.otf
例如我修改后的字体为:
--- Metrics ---
[head] Units per Em:     1000
[head] yMax:         1221
[head] yMin:         -488
[OS/2] TypoAscender:     880
[OS/2] TypoDescender:     -120
[OS/2] WinAscent:     1160
[OS/2] WinDescent:     320
[hhea] Ascent:         1160
[hhea] Descent:     -320

[hhea] LineGap:     0
[OS/2] TypoLineGap:     0

这里面跟ascent相关的有hhea.Ascent、OS/2 TypoAscender和OS/2 WinAscent。对应的不同平台需要的参数。其中前两个在安卓平台有使用到。

研究过程:

使用思源字体在Android TextView中写字,发现字高很奇怪,主要问题是:

(1)字高约为正常字的近3倍。

(2)中文顶部对齐,英文底部对齐。

使用的字体来自:

(1)adobe发布adobe-fonts/source-han-sans

(2)google发布googlei18n/noto-fonts

为了方便测试,使用100sp字号的字进行测试。测试方法为打印FontMetrics的值:

private void printFontMetrics() {
    Paint.FontMetrics metrics = mTextView.getPaint().getFontMetrics();
    Log.e("FONT", "metrics top=" + metrics.top +",ascent=" + metrics.ascent
            + ",descent=" + metrics.descent + ",bottom=" + metrics.bottom
            + ",leading=" + metrics.leading
    );
}

测试的结果大概为以下Python的公式:

#!/usr/bin/env python

from __future__ import print_function
import sys


class Metrics:
    def __init__(self):
        self.leading = 0.0
        self.top = 0.0
        self.ascent = 0.0
        self.descent = 0.0
        self.bottom = 0.0

    def elegant(self, size):
        self.leading = 0
        self.top = -size * 2500.0 / 2048
        self.ascent = -size * 1900.0 / 2048
        self.descent = size * 500.0 / 2048
        self.bottom = size * 1000.0 / 2048

    # (NotoSansHans)top = -180.7,ascent = -88.0,descent = 12.0,bottom = 104.700005,leading = 50.0
    def otf_sans_hans(self, size):
        # top bottom https://raw.githubusercontent.com/adobe-fonts/source-han-sans/1.000/Medium/cidfont.ps.CN
        self.leading = size * 0.5 # OS/2 TypoLineGap / 1000
        self.top = -size * 1.807 # head.yMax
        # https://github.com/adobe-fonts/source-han-sans/blob/1.000/Medium/features.CN
        self.ascent = -size * 0.88 # OS/2 TypoAscender / 1000
        self.descent = size * 0.12 # OS/2 TypoDescender / 1000
        self.bottom = size * 1.047 # head.yMin

    # (NotoSansSC)top = -180.7,ascent = -116.0,descent = 32.0,bottom = 104.700005,leading = 0.0
    def otf_sans_sc(self, size):
        self.leading = 0 # hhea.LineGap
        self.top = -size * 1.807 # head.yMax
        self.ascent = -size * 1.16 # hhea.Ascender
        self.descent = size * 0.32 # hhea.Descender
        self.bottom = size * 1.047 # head.yMin

    # (NotoSerifSC)top = -180.8,ascent = -115.100006,descent = 28.600002,bottom = 104.799995,leading = 0.0
    def otf_serif_sc(self, size):
        self.leading = 0
        self.top = -size * 1.808
        self.ascent = -size * 1.151
        self.descent = size * 0.286
        self.bottom = size * 1.048

    # top = -105.615234,ascent = -92.77344,descent = 24.414063,bottom = 27.09961,leading = 0
    def ttf(self, size):
        self.leading = 0
        self.top = -size * 2163.0 / 2048
        self.ascent = -size * 1900.0 / 2048
        self.descent = size * 500.0 / 2048
        self.bottom = size * 555.0 / 2048

    def printer(self):
        print("top = " + str(self.top)
              + ",ascent = " + str(self.ascent)
              + ",descent = " + str(self.descent)
              + ",bottom = " + str(self.bottom)
              + ",leading = " + str(self.leading))

if __name__ == '__main__':
    metrics = Metrics()

    size = int(sys.argv[1])

    print('elegant:')
    metrics.elegant(size)
    metrics.printer()

    print('NotoSansHans-Medium(1.000):')
    metrics.otf_sans_hans(size)
    metrics.printer()

    print('NotoSansHans-Medium(1.002):')
    metrics.otf_sans_hans(size)
    metrics.leading = 0
    metrics.printer()

    print('NotoSansSC-Medium(1.004):')
    metrics.otf_sans_sc(size)
    metrics.printer()

    print('Native-Medium:')
    metrics.ttf(size)
    metrics.printer()

    print('NotoSerifSC-Medium:')
    metrics.otf_serif_sc(size)
    metrics.printer()

elegant指的是设置textview.setElegantTextHeight(true); 这是Android SDK 21新增的接口,其值来自于android source(frameworks/base/core/jni/android/graphics/Paint.cpp):

static SkScalar getMetricsInternal(JNIEnv* env, jobject jpaint, Paint::FontMetrics *metrics) {
    const int kElegantTop = 2500;
    const int kElegantBottom = -1000;
    const int kElegantAscent = 1900;
    const int kElegantDescent = -500;
    const int kElegantLeading = 0;
    Paint* paint = GraphicsJNI::getNativePaint(env, jpaint);
    TypefaceImpl* typeface = GraphicsJNI::getNativeTypeface(env, jpaint);
    typeface = TypefaceImpl_resolveDefault(typeface);
    FakedFont baseFont = typeface->fFontCollection->baseFontFaked(typeface->fStyle);
    float saveSkewX = paint->getTextSkewX();
    bool savefakeBold = paint->isFakeBoldText();
    MinikinFontSkia::populateSkPaint(paint, baseFont.font, baseFont.fakery);
    SkScalar spacing = paint->getFontMetrics(metrics);
    // The populateSkPaint call may have changed fake bold / text skew
    // because we want to measure with those effects applied, so now
    // restore the original settings.
    paint->setTextSkewX(saveSkewX);
    paint->setFakeBoldText(savefakeBold);
    if (paint->getFontVariant() == VARIANT_ELEGANT) {//那个变量影响的是这个
        SkScalar size = paint->getTextSize();
        metrics->fTop = -size * kElegantTop / 2048;
        metrics->fBottom = -size * kElegantBottom / 2048;
        metrics->fAscent = -size * kElegantAscent / 2048;
        metrics->fDescent = -size * kElegantDescent / 2048;
        metrics->fLeading = size * kElegantLeading / 2048;
        spacing = metrics->fDescent - metrics->fAscent + metrics->fLeading;
    }
    return spacing;
}

还有见到一种调整高度的方式是使用textview.setIncludeFontPadding(false),其原理其实是BoringLayout中使用bottom-top来计算或者是使用descent-ascent来计算而已:

if (includepad) {
    spacing = metrics.bottom - metrics.top;
    mDesc = metrics.bottom;
} else {
    spacing = metrics.descent - metrics.ascent;
    mDesc = metrics.descent;
}

mBottom = spacing;

NotoSansHans是思源黑体的V1.000简体中文版本,最新的版本V1.004改为NotoSansSC。

就以NotoSansSC的参数为例,说明来源:

def otf_sans_sc(self, size):
    self.leading = 0
    self.top = -size * 1.807
    self.ascent = -size * 1.16
    self.descent = size * 0.32
    self.bottom = size * 1.047

其中的leading、ascent、descent来自于字体的hhea参数。

根据adobe-fonts/source-han-sans


table hhea {
Ascender 1160;
Descender -320;
LineGap 0;
} hhea;

可知:


ascent = -hhea.Ascender / 1000
descent = -hhea.Descender / 1000
leading = -hhea.LineGap / 1000

而top、bottom不是来自字体的FontBBox参数,而是head.yMin和head.yMax字段。参考:修正思源黑体在 Adobe 软件中文本选区过高的问题(注意这个答案的方法对Android无效)

通过查看

https://raw.githubusercontent.com/adobe-fonts/source-han-sans/master/Medium/cidfont.ps.CN

其中


/FontBBox {-1007 -1047 2927 1807} def

表示的是xMin/yMin/xMax/yMax。也是1000倍的关系。

如果按照上面elegant的公式,我觉得应该建议改为:


/FontBBox {-1007 -488 2927 1221} def

但是使用字体编译工具修改FontBBox对安卓是无效的。安卓使用的是head.yMin和head.yMax。

解决方法:


ttx -i ./NotoSansSC-Medium.otf
生成字体的ttx文件。

然后使用vi来编辑生成的ttx文件,搜索yMin,找到下面段。



<head>
    <!-- Most of this table will be recalculated by the compiler -->
    <tableVersion value="1.0"/>
    <fontRevision value="1.004"/>
    <checkSumAdjustment value="0x4386f026"/>
    <magicNumber value="0x5f0f3cf5"/>
    <flags value="00000000 00000011"/>
    <unitsPerEm value="1000"/>
    <created value="Mon Jun 15 05:07:55 2015"/>
    <modified value="Mon Jun 15 05:07:55 2015"/>
    <xMin value="-1007"/>
    <yMin value="-1047"/>
    <xMax value="2927"/>
    <yMax value="1807"/>
    <macStyle value="00000000 00000000"/>
    <lowestRecPPEM value="3"/>
    <fontDirectionHint value="2"/>
    <indexToLocFormat value="0"/>
    <glyphDataFormat value="0"/>
  </head>

修改yMin/yMax为:

<yMin value="-488"/>
<yMax value="1221"/>

然后重新编译:


ttx ./NotoSansSC-Medium.ttx
就会得到./NotoSansSC-Medium#1.otf。

下载字体编译工具:
Adobe Font Development Kit for OpenType
http://www.adobe.com/devnet/opentype/afdko/eula.html

如果从头编译(不需要):


makeotf -f cidfont.ps.CN -ff features.CN -fi cidfontinfo.CN -mf ../FontMenuNameDB.SUBSET -r -nS -cs 25 -ch ../UniSourceHanSansCN-UTF32-H

测试好像无效果。

根据小林剑在之前issue里的回复Behaviour of SHS on Android · Issue #88 · adobe-fonts/source-han-sans
https://github.com/adobe-fonts/source-han-sans/issues/88%23issuecomment-77845708
“There are two things happening here, one of which is planning to be changed for the forthcoming Version 1.002 update, and the other points to an issue in Android.

First, we already have plans to change the line gap value, as expressed in the ‘OS/2’, ‘hhea’, and ‘vhea’ tables, from 500 to 0 (zero) in the Version 1.002 update.

Second, the way that both examples are being used is different. Let me explain. The Android Default example is using font fallback whereby the equivalent Noto Sans CJK font is being referenced via the font fallback chain. The Latin font is the primary font, and that is where these so-called vertical metrics are coming from. In other words, the primary font in the font fallback chain is used to determine vertical metrics, which are inherited by (or forced upon) the other fonts in the font fallback chain. (Source Han Sans and Noto Sans CJK are 100% identical except for the names; I know, because I built both families at the same time.)

The issue in Android is that it is ignoring the ascent and descent values that are specified in the ‘OS/2’ table, which would be about 130 and 36, respectively, for your examples. Android is instead using the FontBBox (font bounding box) values, whose somewhat large values are caused by the mere presence of glyphs for the following characters: U+2E3A (vertical), U+2E3B (vertical), U+3031, and U+3032.

Of course, because you are using a version of Android that includes the Noto Sans CJK fonts, there is no reason to replace the fonts with the equivalent Source Han Sans versions, unless you prefer the Western glyphs in Source Han Sans / Noto Sans CJK that are being overridden by the primary font in the font fallback chain.

Anyway, I am keeping this issue open until the Version 1.002 update has been released.

参考:

1、hhea标准(The Horizontal Header Table)
https://www.microsoft.com/typography/otspec/hhea.htm
Windows Metrics Table
https://www.microsoft.com/typography/otspec/os2.htm%23sta
2、修正思源黑体在 Adobe 软件中文本选区过高的问题
https://zhuanlan.zhihu.com/p/19887102
3、tamcy/CYanHeiHK
https://github.com/tamcy/CYanHeiHK/blob/master/doc/FONTBBOX-ADJUSTED-VERSION.md
